Progressive Turf Rollers

The Pro Roll series of fairway rollers are a versatile wide-area turf roller that come in widths of 3,25 m. (10′ 8″) and 4,57 m. (15′)  rolling widths. On top of being ideal for smoothing out fairways, it has also been shown to reduce disease pressure and reduce mowing frequency, all while being gentle enough for use on new growth and delicate turf.

  • 5 rollers
  • Working Width 10'8"
  • Durable Countering Rollers
  • 5 individual floating roller assemblies
  • Pro Lift -N-Turn™
  • Easily Adjustable
  • Towing Flexibility
  • Weight 2400 Lbs (with 6 weights per deck)

Pro-Roll 10 Wide-Area Contour Roller

Within the range of Progressive Turf Rollers, the Pro-Roll 10 is a versatile wide-area turf rollers with 10’8″ rolling width. Ideal for smoothing flat or contoured turf, they have been shown to aid in reducing disease pressure and permit a reduction in mowing frequency and chemical usage. At the same time, the rollers are still gentle enough for use on new growth and delicate turf.

The Pro-Roll 10 produces consistent compaction, regardless of the terrain profile as each roller is able to independently track changing contours. Solid ballast is easily added to or removed from each roller deck allowing even compaction across all rollers.

The Pro-Roll 10 can be used with either a compact tractor or a wide range of utility vehicles.

Whether it is a tight corner of a sports field or negotiating a fairway hazard, the Pro-Roll is able to make sharp turns without scuffing. This is all thanks to the four individually-mounted transport tires, and Progressive’s unique Pro Lift-N-Turn™ system.

Benefits:

Durable Countering Rollers :
Pro-Roll 10’s five individual floating roller assemblies’ conforms to undulating terrain.
Pro Lift-N-Turn™:
Progressive’s exclusive Pro Lift-N-Turn™ system is standard equipment. Allows the user to mow more while never have to turn off the mower.
Easily Adjustable :
Quickly and easily adjust Pro-Roll to changing conditions and desired results.
Towing Flexibility :
A standard 2” ball or optional 4-way swivel hitch provides a wide range of towing options. Two hydraulic hoses connects the tow vehicle to the Pro-Roll. Roller float is built into the Pro-Roll so the tow vehicle does not require a hydraulic float function.
Efficient :
Pro-Roll is designed with the user in mind. By incorporating innovative features that puts the Pro-Roll ahead of the pack when it comes to contour rolling.

Pro-Roll 10 Wide-Area Contour Roller Specifications

Part Number: 670120
Weight: * (Without ballast installed) 1500
Weight: * (With six 30 lb ballast weights per roller) 2400
Ground Pressure: * (Without weights) 5.8 psi
Production: * (Assumes no overlap or turning) 4 mph 5.2 acres per hour*
6 mph 7.8 acres per hour*
8 mph 10.4 acres per hour*
Ground Pressure: * (With 2 weights per roller) 7.7 psi
Ground Pressure: * (With 4 weights per roller) 9.7 psi
Ground Pressure: * (With 6 weights per roller) 11.6 psi



  • 7 rollers
  • Working width 15'
  • Weight 3170 Lbs (with 6 weights per deck)
  • Durable countering rollers
  • Pro Lift-N-Turn™
  • Easily Adjustable
  • Towing flexibility

Pro-Roll 15 Wide-Area Contour Roller

The Pro-Roll 15 is a versatile wide-area turf roller with a 15′ rolling width. Ideal for smoothing flat or contoured turf, they have been shown to aid in reducing disease pressure and permit a reduction in mowing frequency and chemical usage. At the same time, they are gentle enough for use on new growth and delicate turf.

These Progressive turf rollers produce consistent compaction, regardless of the terrain profile, as each roller is able to independently track changing contours. It can be used with either a compact tractor or a wide range of utility vehicles.

Solid ballast is easily added to or removed from each roller deck allowing even compaction across all rollers.

Benefits:

Durable Countering Rollers :
Pro-Roll 15’s seven individual floating roller assemblies’ conforms to undulating terrain.
Pro Lift-N-Turn™:
Progressive’s exclusive Pro Lift-N-Turn™ system is standard equipment. Allows the user to mow more while never have to turn off the mower.
Easily Adjustable:
Quickly and easily adjust Pro-Roll to changing conditions and desired results.
Towing Flexibility :
A standard 2” ball or optional 4-way swivel hitch provides a wide range of towing options. Two hydraulic hoses connects the tow vehicle to the Pro-Roll. Roller float is built into the Pro-Roll so the tow vehicle does not require a hydraulic float function.
Efficient :
Designed with the user in mind, the Pro-Roll incorporates several innovative features that puts the Pro-Roll ahead of the pack when it comes to wide-area and contour rolling.

Pro-Roll 15 Wide-Area Contour Roller Specifications

Part Number: 670168
Weight: * (Without ballast installed) 1910 lbs
Weight: * (With six 30 lb ballast weights per roller) 3170 lbs
Ground Pressure: * (Without weights) 5.8 psi
Production: * (Assumes no overlap or turning) 4 mph 7.3 acres per hour*
6 mph 11 acres per hour*
8 mph 14.5 acres per hour*
Ground Pressure: * (With 2 weights per roller) 7.7 psi
Ground Pressure: * (With 4 weights per roller) 9.7 psi
Ground Pressure: * (With 6 weights per roller) 11.6 psi
Transport Width: 7′ 11″
Transport Tires: Four 18.5 x 8.5 – 8, 4 ply
Transport Height: 6′ 11″
Transport Length: 9′ 9″
Std. Equipment: 4 x 30 lb ballast weights per roller
28 individual weights total
Opt. Equipment: 2 additional 30 lb weights for each roller deck, set of 14
